Product Description

Business in the front, party out back? Sure thing. The Process 134 CR can rock the mullet in style, thanks to its carbon fiber frame and flip-chip versatility. But it can also be the singletrack party that never ends. And it can be the serious as a heart attack backcountry explorer (bear spray not included). Or whatever else you think a mountain bike should be. The same carbon fiber frame as the 134 CR DL, a super dependable SRAM GX cable operated drivetrain, hammer reliable DT Swiss hubs and proven Fox Performance Elite suspension components give the Process 134 CR the any trail, anywhere demeanor that lets you go farther, deeper, bigger.

SPECS & GEOMETRY

SPECIFICATIONS

Frame Material	Kona Carbon 134mm Travel
Sizes	S, M, L, XL
Rear Shock	Fox Float X Performance Elite Trunnion
Fork	Fox Float 34 Performance 140mm Tapered 110mm Spacing
Crankarms	SRAM GX Eagle DUB
Chainrings	32t X-Sync Eagle
B/B	SRAM DUB PF92
Pedals	n/a
Chain	SRAM NX-Eagle
Cassette	SRAM GX-Eagle 10-52t 12spd
Chainguide	n/a
F/D	n/a
R/D	SRAM GX-Eagle
Shifters	SRAM GX-Eagle
Brake Calipers	SRAM G2 R
Front Brake Rotor	SRAM Centerline 200mm
Rear Brake Rotor	SRAM Centerline 200mm
Brake Levers	SRAM G2 R
Headset	FSA Orbit 1.5 E ZS
Handlebar	Kona XC/BC 35
Stem	Kona XC/BC 35
Seatpost	TranzX Dropper +RAD Internal 31.6mm
Seat Clamp	Kona Clamp
Grips	Kona Key Grip
Saddle	WTB Volt
Front Hub	DT Swiss 370 110x15mm
Rear Hub	DT Swiss 370 148x12mm
Spokes	Stainless Black 14g
Rims	WTB KOM Team i30 TCS
Front Tire	Maxxis Minion DHF EXO TR 3C 29x2.5" WT
Rear Tire	Maxxis Dissector EXO TR 3C 29x2.4" WT (27.5x2.4" WT size S)
Paint Color	Gloss Toffee w/ Leather Decals
Extras	n/a

All specifications are subject to change without notice.

GEOMETRY

	Size	S	M	L	XL
1	ST Length	380	380	420	450
2	TT Length	570	599	628	666
3	Reach	430	455	480	515
4	Stack	605	615	625	635
5	Standover	700	700	710	720
6	HT Angle	65.5	65.5	65.5	65.5
7	HT Length	94	105	116	127
8	ST Angle	76.9	76.9	76.7	76.6
9	CS Length	435	435	435	435
10	BB Drop	23	33	33	33
11	BB Height	342	342	342	342
12	Wheelbase	1171	1200	1230	1269
13	Front Center	738	767	797	836
14	Fork Length	551	551	551	551
15	Fork Offset	44	44	44	44

SIZING & SELECTION

MTB FULL SUSPENSION / HARDTAIL / SPLICE

Height/Inches	Height/Metric	Inseam/Inches	Inseam/Metric	MTB/XC Trail/Fat	All Mountain/Enduro	Splice
4'10"-5'1"	147-155cm	24”-27”	61-69cm	XS	XS	Small
5'0"-5'3"	152-160cm	26"-29"	66-74cm	Small	Small	Small
5'2"-5'7"	157-170cm	27"-30"	69-76cm	Small, Medium	Small, Medium	Small, Medium
5'6"-5'10"	168-178cm	29"-31"	74-79cm	Medium	Medium	Medium
5'9"-6'0"	175-183cm	30"-33"	76-84cm	Medium, Large	Medium, Large	Medium, Large
5'11"-6'2"	180-188cm	32"-35"	81-89cm	Large, XL	Large, XL	Large, XL
6'1"-6'5"	185-196cm	33"-36"	84-91cm	Large, XL	Large, XL	Large, XL
