SPEC HIGHLIGHTS
- RockShox Yari RC 160mm fork
- RockShox Deluxe Select Plus rear shock
- Shimano Deore 11spd drivetrain with 11-51t cassette or Microshift Advent X 10spd drivetrain with 11-48t cassette
- Travel-adjust TranzX dropper post
- Shimano Deore or SRAM DB8 disc brakes
| FRAME MATERIAL |
Kona 6061 Aluminum Butted 153mm Travel |
| SIZES |
S, M, L, XL |
|
|
| Rear Shock |
RockShox Deluxe Select Plus Trunnion |
| Fork |
RockShox Yari RC Motion Control DebonAir 160mm Tapered 110mm Spacing |
| Crankarms |
Shimano Deore |
| Chainrings |
30t |
| B/B |
Shimano Deore PF92 |
| Pedals |
n/a |
| Chain |
KMC X11 |
| Freewheel |
Sunrace 11-51t 11spd |
| Chainguide |
n/a |
| F/D |
n/a |
| R/D |
Shimano Deore 11spd |
| Shifters |
Shimano Deore 11spd |
| Brake Calipers |
Shimano Deore |
| Front Brake Rotor |
Shimano RT64 203mm (centerlock) |
| Rear Brake Rotor |
Shimano RT64 180mm (centerlock) |
| Brake Levers |
Shimano Deore |
| Headset |
FSA No.57B |
| Handlebar |
Kona XC/BC 35 |
| Stem |
Kona XC/BC 35 |
| Seatpost |
TranzX Dropper +RAD Internal w/ Shimano Lever 31.6mm |
| Seat Clamp |
Kona Clamp |
| Grips |
Kona Key Grip |
| Saddle |
Kona Trail |
| Front Hub |
Shimano 110x15mm |
| Rear Hub |
Shimano 148x12mm |
| Spokes |
Stainless Black 14g |
| Rims |
WTB ST i30 TCS 2.0 |
| Front Tire |
Maxxis Assegai EXO TR DUAL 27.5x2.5" WT |
| Rear Tire |
Maxxis Minion DHR II EXO TR DUAL 27.5x2.4" WT |
| Paint Color |
Gloss Mocha w/ Black & Orange Decals |
| Extras |
n/a
|
GEOMETRY
|
SIZE |
S |
M |
L |
XL |
| 1 |
ST LENGTH |
385 |
410 |
450 |
485 |
| 2 |
TT LENGTH |
569 |
599 |
628 |
667 |
| 3 |
REACH |
430 |
455 |
480 |
515 |
| 4 |
STACK |
605 |
615 |
625 |
635 |
| 5 |
STANDOVER |
690 |
700 |
710 |
720 |
| 6 |
HT ANGLE |
64.5 |
64.5 |
64.5 |
64.5 |
| 7 |
HT LENGTH |
123 |
134 |
145 |
156 |
| 8 |
ST ANGLE |
77 |
76.9 |
76.7 |
76.6 |
| 9 |
CS LENGTH |
430 |
430 |
430 |
430 |
| 10 |
BB DROP |
12 |
12 |
12 |
12 |
| 11 |
BB HEIGHT |
348 |
348 |
348 |
348 |
| 12 |
WHEELBASE |
1184 |
1213 |
1243 |
1283 |
| 13 |
FRONT CENTER |
754 |
784 |
814 |
853 |
| 14 |
FORK LENGTH |
552 |
552 |
552 |
552 |
| 15 |
FORK OFFSET |
37 |
37 |
37 |
37 |
