Product Description

Specifications

  • FRAME

    All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor

  • FORK

    RockShock 35 Silver R 29", Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset

  • SHOCK

    X-Fusion 02 PRO R, Compression and Rebound Adjustment, Custom Tune, 210x50 25xM8 Lower Mount & Upper Mount

  • RIMS

    Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible

  • HUB REAR

    Shimano HB-MT400B, 148x12mm, Centerlock Disc, Standard Freehub Body

  • HUB FRONT

    Shimano MT-410B, 110x15mm, Centerlock Disc, 32H

  • SPOKES

    14g Black Stainless Steel

  • TIRES

    Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing

  • DERAILLEUR REAR

    Shimano Deore, Direct Attachment, 10-Speed SGS

  • SHIFT LEVER

    Shimano Deore, 10-Speed

  • CRANKSET

    Aluminum, 160mm Length, 38t Chainring

  • MOTOR

    Shimano Steps EP6 Drive Unit, 250W, 85Nm

  • CHAIN

    KMC X-10E, Silver

  • CASSETTE

    Shimano Deore 10-speed 11-46T

  • BRAKES FRONT

    TRP Slate Evo, 4-Piston Hydraulic Disc, Brake 203mm Rotor

  • BRAKES REAR

    TRP Slate Evo, 4-Piston Hydraulic Disc, Brake 203mm Rotor w/ Speed Sensor

  • BRAKE LEVERS

    TRP Slate Evo

  • HANDLEBAR

    Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

  • STEM

    Marin 3D Forged Alloy, 35mm

  • GRIPS

    Marin Grizzly Lock On

  • HEADSET

    FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

  • SEATPOST

    TranzX, YSP18JL, 1x Remote, Size S 150mm Travel, All Other Sizes 170mm Travel, 30.9mm

  • SADDLE

    Marin eMTB Saddle

  • PEDALS

    Marin MTB Plastic

  • BATTERY

    Shimano BT-EN805L, Internal 504Wh

  • DISPLAY

    Shimano SC-E600

  • SWITCH

    Shimano SW-EN600L Left Hand Switch for Assist Mode Change

  • EXTRAS

    Shimano Battery Charger EC-E6002, Shimano CS-EN800 Chainguide

Specifications, pricing, and availability are subject to change without notice.

Geometry

Rift Zone E geometry diagram
S M L XL
Stack 606.98 614.04 625.1 634.16
Reach 445 465 485 515
Head Tube Angle 65° 65° 65° 65°
Head Tube Length 100 110 120 130
Seat Tube Angle 77° 77° 77° 77°
Seat Tube Length 390 400 425 435
Top Tube Effective 585.13 607.22 629.32 661.41
BB Height 348.5 348.5 348.5 348.5
BB Drop 32 32 32 32
Chainstay 440 440 440 440
Wheelbase 1198.29 1222.52 1246.74 1280.97
Standover Height 693.65 696.01 709.94 719.93
Fork Offset 42 42 42 42
Seatpost Diameter 30.9 30.9 30.9 30.9
Handlebar Width 780 780 780 780
Stem Length 35 35 35 35
Crank Length 160 160 160 160

All lengths in millimeters

Technology

Rift Zone E1 toptube detail.

SERIES 4 ALUMINUM FRAME

Rift Zone E models are built upon our Series 4 aluminum frames, with detailed forgings, highly manipulated tubes, and full internal cable routing, giving the rider the highest-end alloy frame that Marin offers, compatible with modern coil or air shocks.

Rift Zone E1 suspension detail.

MULTITRAC SUSPENSION

The Alpine Trail E features the same great, proven MultiTrac suspension technology, but optimized for the Shimano STEPS system, with 140mm of suspension for the best on-trail experience.

Shimano STEPs drive unit detail.

SHIMANO STEPS

Shimano’s STEPS system is both powerful and lightweight, with the mid-drive motor down low to help ensure that the Rift Zone E performs like the analog version, but with a 250W boost. Three levels of power give riders options to balance electric power, speed and range. Electric assist up to 20mph in the US, 25km/h in Europe.
