Product Description

In Stock with supplier 10-12 days delivery

More autonomy, more connectivity and the latest Bosch technology featured in an accessible package. From off road commuting to your local trails, the Aspect is all about versatility and fun.

Please note that bike specifications are subject to change without prior notice

Specs

Frame: Alloy S-XL=29" / 6061 Alloy custom butted tubing; Top extraction battery; UDH Interface / 12x148mm with 52mm Chainline

Travel: 120mm

Fork: SR Suntour XCM34 RL Coil / Tapered 120mm Travel / 15x110 bolt Axle / Remote Lock Out

Remote System: SR Suntour Remote

Drive Unit: Bosch Performance CX; EU: 25kmh

Battery: PowerTube 600Wh

Display: Bosch LED Remote; Intuvia 100

Charger: 2A Charger

Rear Derailleur: SRAM NX Eagle / 12 Speed

Shifters: SRAM SX Eagle Single Click Trigger

Crankset: FSA CK-220; 165mm

Chainring: SRAM CR T-Type 36T DM w/Chain Guard

Chain: SRAM SX Eagle

Cassette: SRAM PG1210 / 11-50

Brakes: Shimano BR-MT420 Disc Brakes

Rotor: Front: SM-RT30 CL 180mm / Rear: SM-RT30 CL 180mm

Handlebar: Syncros 3.0 720mm / 31.8mm / 9° / 12mm rise; Syncros Comfort lock-on grips

H'stem: Syncros AM2.0 / 6061 Alloy; 31.8mm / 0°

Seatpost: Syncros M3.0 / 31.6mm; 350mm

Seat: Syncros Tofino E 2.0

Headset: Acros / 1.5"- 1.5"; semi integ. OD 50/61mm / ID 44/55mm

Hub (Front): Formula CL-811 / 15x110mm

Hub (Rear): Formula CL-148S / 148x12mm

Spokes: Stainless Black

Rims: Cross X19 / 32H / 30mm / Pin Joint; Tubeless ready

Front Tire: Kenda Booster 29x2.6" / 30TPI

Rear Tire: Kenda Booster 29x2.6" / 30TPI

Lights: Bosch Light Cable pre-installed F&R

Approx weight in KG: 27.7

Approx weight in LBS: 61.07

Max. System Weight

128kg

The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

mminches

		S / 900	M / 900	L / 900	XL / 900
A	head tube angle	67.0 °	67.0 °	67.0 °	67.0 °
B	head tube length	160.0 mm	160.0 mm	170.0 mm	170.0 mm
C	top tube horizontal	575.0 mm	595.0 mm	615.0 mm	615.0 mm
D	standover height	638.0 mm	633.0 mm	630.0 mm	630.0 mm
E	BB offset	-63.0 mm	-63.0 mm	-63.0 mm	-63.0 mm
F	BB height	315.0 mm	315.0 mm	315.0 mm	315.0 mm
G	wheel base	1,205.0 mm	1,225.0 mm	1,247.0 mm	1,247.0 mm
H	BB center to toptube center
I	BB center to top of seattube	440.0 mm	480.0 mm	520.0 mm	560.0 mm
J	seat angle	75.8 °	75.8 °	75.8 °	75.8 °
K	chainstay	482.0 mm	482.0 mm	482.0 mm	482.0 mm
L	reach	399.0 mm	419.0 mm	437.0 mm	437.0 mm
M	stack	696.0 mm	696.0 mm	705.0 mm	705.0 mm
N	stem length	50.0 mm	50.0 mm	60.0 mm	60.0 mm
0	trail	110.0 mm	111.0 mm	111.0 mm	111.0 mm
